2. hot air station thermostatic control, stepless adjustment of air volume, rapid heating, safe desoldering QFP, PLCC, SOP, BGA and other temperature-sensitive components.
3. set the time delay automatic cooling system, after the shutdown delay completion of the work of air, about a minute after the automatic shutdown, better prolong heater life and protect the hot air gun!
4. anti-static high temperature resistant silicone tube connecting the handle to the console, suitable for different non-member desoldering SMD, quick start up quickly, with the open with the use!
5. the soldering station handle special lightweight, suitable for prolonged use, especially suitable for SMD mount components by hand, rework and the general components of the in-line welding and soldering various other process requirements.
6. imported long life fever materials and advanced processing technology, assembled into a high-power heating element, long life
7. the combo design, saving work space, and each function can be used independently.
8. the new pump, low noise, low vibration, long life, durable.
Note: The bottom of the fuselage must be removed before using the middle of the three screws, the screws in order to transport them with a fixed pump.
Applications:
1. various types of electronics industry and factories desoldering operations.
2. thermal plastic welding industry jobs.
3. home appliances and electronics repair and maintenance work.
4. all kinds of PVC / PE / PP / PVDF plastic materials such as board, pipe, film sheet spot welding.
5. each electron Universities teaching and practice of operational applications.
Specifications
Model
TAIKD-952D
Voltage
AC 220V/50Hz
Total power
330W
Hot air station temperature range
100-420°C Stepless
Pump form
Diaphragm
Gas flow
0.3～24L/min Stepless
Pump power
45W
Hot air heating core units
Imported four-wire 250W heater
Noise
<40dB
Welding power station
60W
Output voltage soldering station
~24V
Soldering station temperature range
200-480°C
Overall size
(L)305×(W)290×(H)172mm
Weight
4.85kg
